Fig. 303: View Of Flywheel Housing To Upper Oil Pan Bolts
Courtesy of GENERAL MOTORS CORP.
5. Install the two flywheel housing to upper oil pan bolts.
Tighten: Tighten the bolts to 50 N.m (37 lb ft).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 304: View Of Battery Cable Bracket Bolts At Lower Crankcase
Courtesy of GENERAL MOTORS CORP.
6. Install the battery cable bracket bolts.
Tighten: Tighten the bolts to 12 N.m (106 lb in).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 305: View Of Battery Cable Bracket Nut
Courtesy of GENERAL MOTORS CORP.
7. Install the battery cable bracket nut.
Tighten: Tighten the nut to 8 N.m (71 lb in).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 306: Oil Level Indicator Tube
Courtesy of GENERAL MOTORS CORP.
8. Install the engine flywheel. Refer to Engine Flywheel Replacement.
9. Install the lower oil pan. Refer to Lower Oil Pan Replacement.
10. If vehicle is a 4WD, install the front differential carrier. Refer to Differential Carrier
Assembly Replacement (1500 FWD) or Differential Carrier Assembly Replacement
(2500 4WD) .
11. If vehicle is a 2WD, Connect the relay rod to the pitman arm and idler arm. Refer to Relay
Rod Replacement .
12. Lower the vehicle.
13. Install the oil level indicator tube bolt to the indicator tube bracket.
