37. Remove the rear power steering pump-to-engine block bolt.
38. Remove the generator bracket mounting bolts.
39. Position the bracket aside.
40. Remove the ignition coil, as required for the proper fit of the J 41798 before lifting the
engine. See Special Tools. Refer to Ignition Coil Replacement .
Fig. 253: View Of J 41798
Courtesy of GENERAL MOTORS CORP.
NOTE:
Refer to Fastener Notice .
2008 Hummer H2
2008 ENGINE Engine Mechanical - 6.2L - H2
41. Install the J 41798 to the cylinder heads. See Special Tools.
Tighten:
Tighten the M8 engine lift bracket bolts to 25 N.m (18 lb ft).
Tighten the M10 engine lift bracket bolts to 50 N.m (37 lb ft).
Fig. 254: View Of Engine Mount-To-Engine Mount Bracket
Courtesy of GENERAL MOTORS CORP.
2008 Hummer H2
2008 ENGINE Engine Mechanical - 6.2L - H2
42. Remove the left and right engine mount-to-engine mount bracket bolts.
43. Raise and suitably support the vehicle. Refer to Lifting and Jacking the Vehicle .
Fig. 255: Engine Protection Shield
Courtesy of GENERAL MOTORS CORP.
44. Remove the engine shield bolts and shield.
2008 Hummer H2
2008 ENGINE Engine Mechanical - 6.2L - H2
