Chevrolet Silverado / GMC Sierra. Manual - part 2999
Fig. 109: Pressing Window Into Place
Courtesy of GENERAL MOTORS CORP.
24. Press the window firmly into place.
25. Tape the window to the body in order to minimize movement until the urethane adhesive
cures.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 110: Cleaning Window
Courtesy of GENERAL MOTORS CORP.
26. Clean any excess urethane adhesive from the body.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 111: Performing Water Hose Test
Courtesy of GENERAL MOTORS CORP.
27. Use a soft spray of warm water in order to immediately water test the window.
28. Inspect the window for leaks.
29. If any leaks are found, use a plastic paddle in order to apply extra urethane adhesive at the
leak point.
30. Retest the window for leaks.
IMPORTANT: Do not direct a hard stream of high pressure water to the
freshly applied urethane adhesive.
CAUTION: Insufficient curing of urethane adhesive may allow
unrestrained occupants to be ejected from the vehicle
resulting in personal injury.
For the moisture-curing type of urethane adhesive,
allow a minimum of 6 hours at 21°C (70°F) or greate r
and with at least 30 percent relative humidity. Allow
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
31. Maintain the following conditions in order to properly cure the urethane adhesive:
Partially lower a door window in order to prevent pressure buildups when closing
doors before the urethane adhesive cures.
Do not drive the vehicle until the urethane adhesive is cured. Refer to the above curing
times.
Do not use compressed air in order to dry the urethane adhesive.
32. Complete the window installation.
FRONT SIDE DOOR WINDOW FRONT CHANNEL AND REAR CHANNEL REPLACEMENT
Fig. 112: View Of Front Door Window Channel & Bolt
Courtesy of GENERAL MOTORS CORP.
at least 24 hours for the complete curing of the
urethane adhesive.
For the chemical-curing type of urethane adhesive,
allow a minimum of 1 hour.
Do NOT physically disturb the repair area until after these
minimum times have elapsed.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
