Courtesy of GENERAL MOTORS CORP. REAR SIDE DOOR WINDOW REGULATOR MOTOR REPLACEMENT (CREW CAB) Callout Component Name Preliminary Procedures 1. Position the door window as needed for service. 2. Remove the rear door window regulator. Refer to Rear Side Door Window Regulator Replacement (Crew Cab, Manual) or Rear Side Door Window 1 Rear Side Door Window Regulator Motor Bolt (Qty :3) Tighten: 9 N.m (80 lb in) NOTE: Refer to Fastener Notice . 2 Rear Side Door Window Regulator Motor
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 79: View Of Rear Side Door Window Regulator Motor & Bolt Callout Component Name Preliminary Procedures 1. Position the door window as needed for service. 2. Remove the rear door window regulator. Refer to Rear Side Door Window Regulator Replacement (Crew Cab, Manual) or Rear Side Door Window 1 Rear Side Door Window Regulator Motor Bolt (Qty: 3) NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
FRONT SIDE DOOR WINDOW OUTER SEALING STRIP REPLACEMENT Fig. 80: View Of Front Side Door Outer Belt Sealing Strip Tighten: 9 N.m (80 lb in) 2 Rear Side Door Window Regulator Motor Callout Component Name Preliminary Procedure 1. Position the door window as needed for service. 2. Tape off the lower window frame to prevent damage to the door. 3. Remove the outside mirror. Refer to Power Mirror Replacement . Front Side Door Outer Belt Sealing Strip
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
FRONT SIDE DOOR WINDOW BELT INNER SEALING STRIP REPLACEMENT Fig. 81: Front Side Door Inner Belt Sealing Strip 1 Procedure 1. Lifting upward on the sealing strip end in order to unhook it from the inside door flange. 2. Install the sealing strip to the flange of the door and push downward until fully seated. Callout Component Name Preliminary Procedure: Front Side Door Inner Belt Sealing Strip
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
