Fig. 76: View Of Rear Side Door Window Regulator, Nuts & Bolt Callout Component Name Preliminary Procedures 1. Position the door window as needed for service. 2. Remove the rear door trim panel. Refer to Rear Side Door Trim Panel Replacement (YE9) or Rear Side Door Trim Panel Replacement (SLT) . 3. Remove the rear door water deflector. Refer to Rear Side Door Water Deflector Replacement . Rear Side Door Window Regulator Bolt
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
REAR SIDE DOOR WINDOW REGULATOR REPLACEMENT (CREW CAB, POWER) 1 Procedure 1. Place the door window in the up position 2. Tape the window to the door frame to prevent it from moving. 3. Loosen the upper bolts that attach the window regulator to the inner door. Tighten: 9 N.m (80 lb in) NOTE: Refer to Fastener Notice . 2 Rear Side Door Window Regulator Nuts (Qty: 2) Tighten: 9 N.m (80 lb in) 3 Rear Side Door Window Regulator Procedure 1. Disconnect the electrical connector. 2. Transfer the power window motor to the new regulator. Refer to Rear Side Door Window Regulator Motor Replacement (Extended Cab)
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 77: View Of Rear Side Door Window Regulator & Bolts Callout Component Name Preliminary Procedures 1. Position the door window as needed for service. 2. Remove the rear door trim panel. Refer to Rear Side Door Trim Panel Replacement (YE9) or Rear Side Door Trim Panel Replacement (SLT) . 3. Remove the rear door water deflector. Refer to Rear Side Door Water Deflector Replacement . 1 Rear Side Door Window Regulator Bolt (Qty: 5) Procedure 1. Tape the window to the door frame to prevent it from moving. 2. Loosen the 2 bolts that attach the window to the window regulator. NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
REAR SIDE DOOR WINDOW REGULATOR MOTOR REPLACEMENT (EXTENDED CAB) Fig. 78: View Of Rear Side Door Window Regulator Motor & Bolts Tighten: 9 N.m (80 lb in) 2 Rear Side Door Window Regulator Procedure 1. Disconnect the electrical connector. 2. Transfer the power window motor to the new regulator. Refer to Rear Side Door Window Regulator Motor Replacement (Extended Cab)
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
