Fig. 54: View Of Transfer Case Shift Control Switch The Magna Powertrain (MP) 1625/1626 RPO NQF transfer case features a 3 mode shift control
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Transfer Case - MP 1625/1626-NQF - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
remain ON constantly. In the event that the transfer case shift control module can not or will not The MP 1625/1626 transfer case provides the driver with 4 manual mode/range positions: 2HI - 2 Wheel Drive high range 4HI - 4 Wheel Drive high range 4LO - 4 Wheel Drive low range, 2.68:1 gear ratio reduction NEUTRAL The driver may choose to select any of these mode/range positions while driving the vehicle. The ignition switch is in RUN. The automatic transmission is in PARK or NEUTRAL. The vehicle speed is below 5 km/h (3 mph). This transfer case also has a NEUTRAL position. A shift to the NEUTRAL position allows the The ignition switch is in RUN. The automatic transmission is in PARK or NEUTRAL. The vehicle speed is below 5 km/h (3 mph). The transfer case is in 2HI mode. Once these conditions have been met, press and hold both the 2HI and 4LO buttons for 10 A shift to the NEUTRAL position allows the vehicle to be towed without rotating the
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Transfer Case - MP 1625/1626-NQF - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
The NQF transfer case is available in 2 variations, depending on the engine and transmission MP 1625/1626 Variations All Canadian MP1625 Transfer Cases will be equipped with the 2300 series round pin chain. Additional differences in these models are listed below: MP1625: The input shaft seal is a single lip seal used only with dry cavity adapters MP1626: The input shaft seal is a dual lip seal used specifically for the MW7 which has a 2WD Mode Power Flow Model Transmission Input Output Shaft Chain Size Chain Series Hi/Low Planetary Application MP 1625 MYD - 6L90 29T Spline 31T Spline 7/16 X 1.5 in 9600 Series Rocker Pin Chain 5 Pinion K2 MP 1626 MYD - 6L90 MW7 - 29T Spline 31T Spline 7/16 X 1.5 in 2300 Series Round Pin Chain 5 Pinion K2, K3
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Transfer Case - MP 1625/1626-NQF - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 55: View Of 2WD Mode Power Flow The transfer case is shifted by an encoder motor (9) on the control actuator shaft. The control 4HI Mode Power Flow
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Transfer Case - MP 1625/1626-NQF - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
