Fig. 16: Removing Rear Output Shaft Seal With Flathead Screwdriver 1. Raise and suitably support the vehicle. Refer to Lifting and Jacking the Vehicle . 2. Remove the transfer case shield, if equipped. Refer to Transfer Case Shield Replacement. 3. Remove the rear propeller shaft. Refer to One-Piece Propeller Shaft Replacement or
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Transfer Case - BW 4485-NR3 - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Two-Piece Propeller Shaft Replacement . 4. Remove the rear output shaft seal by prying it out with a flat tipped screwdriver. Installation Procedure Fig. 17: View Of Front Output Shaft Seal Installation Special Tool 1. Using the J 45756 , install a NEW front output shaft seal. See Special Tools. 2. Install the rear propeller shaft. Refer to One-Piece Propeller Shaft Replacement or Two- Piece Propeller Shaft Replacement . 3. Check the fluid level. Add fluid, if necessary. 4. Install the transfer case shield, if equipped. Refer to Transfer Case Shield Replacement. 5. Lower the vehicle. TRANSFER CASE ASSEMBLY REPLACEMENT
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Transfer Case - BW 4485-NR3 - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Removal Procedure 1. Raise and suitably support the vehicle. Refer to Lifting and Jacking the Vehicle . 2. Remove the transfer case shield, if equipped. Refer to Transfer Case Shield Replacement. 3. Remove the rear propeller shaft. Refer to One-Piece Propeller Shaft Replacement or Two-Piece Propeller Shaft Replacement . 4. Remove the front propeller shaft. Refer to Front Propeller Shaft Replacement . 5. Drain the fluid from the transfer case. 6. Support the transmission with a suitable jack stand.
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Transfer Case - BW 4485-NR3 - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 18: Identifying Transmission Mount Nuts 7. Remove the transmission mount nuts and bolts.
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Transfer Case - BW 4485-NR3 - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
