Tighten: Tighten the screws to 4 N.m (35 lb in). Crew Cab has two screws. Extended Cab has three screws. SUNROOF WINDOW REPLACEMENT (EXTENDED CAB) Removal Procedure Fig. 58: View Of Sunroof Window Panel Screws 1. Position the sunshade panel fully rearward. 2. Position the sunroof window panel to the vent position. 3. Remove the sunroof window panel screws from the sunroof window panel. 4. Remove the sunroof window panel from the sunroof module.
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Installation Procedure Fig. 59: View Of Sunroof Window Panel Screws 1. Position the sunroof window panel to the sunroof module. Ensure that the information logo stencil is towards the rear of the sunroof opening. 2. Install the sunroof window panel screws to the sunroof window panel. Tighten: Tighten the sunroof window panel screws to 4 N.m (35 lb in). 3. Adjust the sunroof window panel as necessary. Refer to Sunroof Window Height and Opening Fit Adjustment. NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
4. Inspect the sunroof window panel for proper operation. SUNROOF WINDOW REPLACEMENT (CREW CAB) Removal Procedure 1. Open the sunshade panel. Fig. 60: Sunroof Window And Retaining Screws IMPORTANT: The sunroof must be in the fully closed position prior to removing the sunroof window.
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
2. Remove the 4 screws (2) that retain the sunroof window (1) to the sunroof module assembly. 3. Remove the sunroof window from the top of the vehicle. Installation Procedure Fig. 61: Sunroof Window And Retaining Screws 1. Position the sunroof window (1) to the vehicle. 2. Loosely insert the screws (2) that retain the sunroof window (1) to the sunroof module assembly.
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
