2. Carefully remove the sunroof window weatherstrip from the perimeter of the sunroof
window.
Installation Procedure
Fig. 54: View Of Weatherstrip
Courtesy of GENERAL MOTORS CORP.
1. Carefully install the sunroof window weatherstrip (2) to the perimeter of the sunroof
window (1), ensuring that the weatherstrip is fully seated.
2. Install the sunroof window to the sunroof module assembly. Refer to Sunroof Window
Replacement (Extended Cab) or Sunroof Window Replacement (Crew Cab).
3. Ensure that the sunroof does not have any air or waterleaks.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
SUNROOF WINDOW WEATHERSTRIP REPLACEMENT (EXTENDED CAB)
Removal Procedure
1. Remove the sunroof window. Refer to Sunroof Window Replacement (Extended Cab)
or Sunroof Window Replacement (Crew Cab).
Fig. 55: View Of Weatherstrip
Courtesy of GENERAL MOTORS CORP.
2. Carefully remove the sunroof window weatherstrip (2) from the perimeter of the sunroof
window (1).
Installation Procedure
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 56: View Of Weatherstrip
Courtesy of GENERAL MOTORS CORP.
1. Carefully install the sunroof window weatherstrip (2) to the perimeter of the sunroof
window (1), ensuring that the weatherstrip is fully seated.
2. Install the sunroof window. Refer to Sunroof Window Replacement (Extended Cab) or
Sunroof Window Replacement (Crew Cab).
3. Ensure that the sunroof does not have any air or waterleaks.
SUNROOF WINDOW HEIGHT AND OPENING FIT ADJUSTMENT
1. Open the sunshade.
2. Close the sunroof window.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 57: Identifying 3 Adjusting Screws
Courtesy of GENERAL MOTORS CORP.
3. Loosen the adjusting screws on each side of the sunroof window.
Crew Cab has two screws.
Extended Cab has three screws.
4. Adjust the corners of the window panel using the following guidelines:
Adjust the front of the sunroof window flush to 2 mm (0.08 in) below the top surface
of the roof panel.
Adjust the rear of the sunroof window flush to 2 mm (0.08 in) above the top surface of
the roof panel.
5. Install the sunroof window adjustment screws.
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
