Chevrolet Silverado / GMC Sierra. Manual - part 2776
Fig. 16: Hose Clip Securing Drain Hose To Vehicle
Courtesy of GENERAL MOTORS CORP.
3. Remove the hose clip securing the drain hose to the vehicle, right or left side, as needed.
4. Remove the drain hose from the vehicle, right or left side, as needed.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Installation Procedure
Fig. 17: Hose Clip Securing Drain Hose To Vehicle
Courtesy of GENERAL MOTORS CORP.
1. Route the end of the drain hose through the access hole and down the inner side panel, right
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
or left side, as needed.
2. Install the hose clip to the door frame securing the drain hose to the vehicle, right or left
side, as needed.
Fig. 18: Rear Sunroof Drain Hose From The Sunroof Module Rear Spigot
Courtesy of GENERAL MOTORS CORP.
3. Connect the rear drain sunroof hose to the sunroof module rear spigot, right or left side, as
needed.
4. Install the headliner. Refer to Headlining Trim Panel Replacement (Regular Cab) or
Headlining Trim Panel Replacement (Crew Cab) or Headlining Trim Panel
Replacement (Extended Cab) .
SUNROOF OPENING TRIM FINISH LACE REPLACEMENT (EXTENDED CAB)
Removal Procedure
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 19: View Of Sunroof Finishing Lace
Courtesy of GENERAL MOTORS CORP.
1. Beginning at the joint located in the center rear of the lace of the sunroof opening, pull the
sunroof finishing lace from the sunroof window track assembly.
2. Remove the sunroof finishing lace from the track.
Installation Procedure
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
