Chevrolet Silverado / GMC Sierra. Manual - part 2714
Fig. 19: View Of Power Steering Pump Rear Bracket Retaining Nuts
Courtesy of GENERAL MOTORS CORP.
7. Remove the power steering pump rear bracket nuts.
2008 Chevrolet Silverado 1500
2008 STEERING Power Steering - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 20: Power Steering Pump & Mounting Bolts
Courtesy of GENERAL MOTORS CORP.
8. Remove the power steering pump bolts.
2008 Chevrolet Silverado 1500
2008 STEERING Power Steering - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 21: Accessory Mounting Bracket
Courtesy of GENERAL MOTORS CORP.
9. Remove the power steering pump bracket bolts and nut.
10. Pull the power steering pump bracket forward.
11. Separate the power steering pump assembly from the power steering pump bracket.
2008 Chevrolet Silverado 1500
2008 STEERING Power Steering - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 22: View Of Power Steering Pressure Hose & Power Steering Pump
Courtesy of GENERAL MOTORS CORP.
12. Remove the power steering gear inlet hose (2) from the power steering pump assembly (1).
13. Remove the power steering pump assembly from the vehicle.
14. Transfer any parts as needed.
Installation Procedure
1. Position the power steering pump assembly in the vehicle with the power steering pump
bracket.
2008 Chevrolet Silverado 1500
2008 STEERING Power Steering - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
