Chevrolet Silverado / GMC Sierra. Manual - part 2712
Fig. 12: View Of Power Steering Pump Rear Bracket & Bolts
Courtesy of GENERAL MOTORS CORP.
3. Remove the power steering pump rear bracket bolts (1).
4. Pull the power steering pump away from the accessory bracket to gain access to the pulley.
2008 Chevrolet Silverado 1500
2008 STEERING Power Steering - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 13: View Of Power Steering Pump Pulley Remover
Courtesy of GENERAL MOTORS CORP.
5. Use the J 25034-C to remove the power steering pump pulley. See Special Tools.
Installation Procedure
2008 Chevrolet Silverado 1500
2008 STEERING Power Steering - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 14: View Of Power Steering Pump Pulley Installer
Courtesy of GENERAL MOTORS CORP.
1. Place the power steering pump pulley on the end of the power steering pump shaft.
2. Install the power steering pump pulley using the J 25033-C . See Special Tools.
2008 Chevrolet Silverado 1500
2008 STEERING Power Steering - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 15: Checking Power Steering Pump Pulley Installed Depth
Courtesy of GENERAL MOTORS CORP.
3. Ensure that the power steering pump pulley (1) is flush against the power steering pump
shaft (2) with an allowable variance of 0.25 mm (0.010 in).
4. Reposition the power steering pump to the accessory bracket.
2008 Chevrolet Silverado 1500
2008 STEERING Power Steering - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
