Fig. 208: Inspecting Axial Play
Courtesy of GENERAL MOTORS CORP.
20. Install the gear train 5th gear synchronizer assembly and inspect the axial play. The retainer
is optional.
Specification: 0.0127-0.0533 cm (0.005-0.021 in)
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 209: Applying Sealant
Courtesy of GENERAL MOTORS CORP.
21. Clean the surface and apply sealant.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 210: Screws Securing Bearing Retainer
Courtesy of GENERAL MOTORS CORP.
22. Tighten the 7 screws.
Tighten: Tighten the screws to 16-27 N.m (12-20 lb ft).
TRANSMISSION ASSEMBLE
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
