Chevrolet Silverado / GMC Sierra. Manual - part 2648
Fig. 204: Retainer Securing Gear Train Bearing Race
Courtesy of GENERAL MOTORS CORP.
16. Using retainer pliers, install the retainer that secures the gear train bearing cup.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 205: Inspecting Axial Play Of Gear Train
Courtesy of GENERAL MOTORS CORP.
17. Inspect the axial play of the gear train.
Specification: 0.0025-0.0127 cm (0.001-0.005 in)
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 206: Drive Wheel
Courtesy of GENERAL MOTORS CORP.
18. Install the drive wheel.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
