Chevrolet Silverado / GMC Sierra. Manual - part 2607
Fig. 45: Using 10 Mm Socket On Vehicle Speed Sensor Housing Bolt
Courtesy of GENERAL MOTORS CORP.
5. Using a 10 mm socket, remove the vehicle speed sensor housing bolt.
6. Remove the vehicle speed sensor.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 46: Using 10 Mm Socket On 12 Bolts At Transmission Rear Case
Courtesy of GENERAL MOTORS CORP.
7. Using a 10 mm socket, remove the 12 bolts from the transmission rear case.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 47: Separating Transmission Rear Case From Transmission Case
Courtesy of GENERAL MOTORS CORP.
8. Using a rubber hammer, tap lightly in order to separate the transmission rear case from the
transmission case.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
