Chevrolet Silverado / GMC Sierra. Manual - part 2580
Fig. 234: Roll Pin
Courtesy of GENERAL MOTORS CORP.
20. Install the roll pin.
21. Position the speedometer gear.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 235: Speedometer Tracking Balls
Courtesy of GENERAL MOTORS CORP.
22. Install the speedometer gear tracking sphere.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 236: Yoke Spacer
Courtesy of GENERAL MOTORS CORP.
23. Install the yoke spacer.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
