Chevrolet Silverado / GMC Sierra. Manual - part 2574
Fig. 209: Applying Gasket Maker
Courtesy of GENERAL MOTORS CORP.
16. Ensure the surface is free from dust and grease and apply gasket maker GMM P/N 1052943.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 210: Control Cover
Courtesy of GENERAL MOTORS CORP.
17. Install the control cover onto the case, assuring the shift forks are aligned with the
corresponding synchronizers.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 211: Using 1/2 Socket On Screws Holding Control Cover
Courtesy of GENERAL MOTORS CORP.
18. Using a 1/2 socket, tighten the 10 screws on the control cover.
Tighten: Tighten the screws to 20-24 N.m (18-22 lb ft).
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 212: Using Ratchet On Breather Support Screw
Courtesy of GENERAL MOTORS CORP.
19. Using a 13 mm socket, tighten the breather support screw.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
