Chevrolet Silverado / GMC Sierra. Manual - part 2573
Fig. 205: 5th Gear, Reverse Shaft, And Fork Assembly
Courtesy of GENERAL MOTORS CORP.
12. Install the 5th and reverse gear fork and shaft, placing the spheres on the insert marks.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 206: Retaining Plate Screws
Courtesy of GENERAL MOTORS CORP.
13. Using a 1/2 socket, tighten the 2 screws on the insert system support plate.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 207: Pins And Lock
Courtesy of GENERAL MOTORS CORP.
14. Install the roll pins .
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 208: Screws Retaining Support Plate On Block
Courtesy of GENERAL MOTORS CORP.
15. Using a 1/2 socket, tighten the 3 screws on the locking system support plate.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
