Chevrolet Silverado / GMC Sierra. Manual - part 2539
Fig. 74: Roller Cage
Courtesy of GENERAL MOTORS CORP.
23. Remove the roller cage from the reverse gear.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 75: Reverse Synchronizer Ring
Courtesy of GENERAL MOTORS CORP.
24. Remove the reverse synchronizer ring.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 76: Snap Ring Holding Reverse Clutch Ring
Courtesy of GENERAL MOTORS CORP.
25. Using locking pliers, remove the snap ring from the reverse clutch ring.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 77: Reverse Clutch Bearing
Courtesy of GENERAL MOTORS CORP.
26. Remove the reverse clutch bearing.
SHIFT SHAFT AND FORK ASSEMBLIES DISASSEMBLE
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
