Chevrolet Silverado / GMC Sierra. Manual - part 2533
Fig. 50: Extension Housing Oil Seal
Courtesy of GENERAL MOTORS CORP.
24. Remove the extension housing oil seal.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 51: Snap Ring
Courtesy of GENERAL MOTORS CORP.
25. Remove the bearing snap ring from the extension housing, if equipped.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 52: Bearing
Courtesy of GENERAL MOTORS CORP.
26. Remove the bearing from the extension housing, if equipped.
MAIN SHAFT DISASSEMBLE
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 53: Main Shaft Assembly In Vertical Position
Courtesy of GENERAL MOTORS CORP.
1. Use a flange or some other type of tool to place the assembly in a vertical position.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
