Fig. 45: Bearing Retainer
Courtesy of GENERAL MOTORS CORP.
19. Remove the bearing retainer.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 46: Drive Shaft
Courtesy of GENERAL MOTORS CORP.
20. Remove the drive shaft.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 47: Tapered Bearing Cup
Courtesy of GENERAL MOTORS CORP.
21. Remove the tapered bearing cup.
Fig. 48: Main Shaft Assembly
Courtesy of GENERAL MOTORS CORP.
22. Remove the main shaft assembly.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
