Fig. 93: Removing/Installing Heater Hose To Engine 2. Install the outlet heater hose to the water pump. 3. Install the outlet heater hose to the surge tank. 4. Install the outlet heater hose clamp to the surge tank.
2008 Chevrolet Silverado 1500 2008 HVAC Heating, Ventilation, and Air Conditioning - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 94: Connecting Quick-Connect Fittings 5. Connect the heater and surge tank hoses to the heater core. 6. Pull the heater outlet hose to ensure the connection. 7. Install the heater and surge tank hoses to the mounting clip. 8. Install the air intake tube. 9. Fill the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill) or Cooling System Draining and Filling (Static Fill) . AIR INLET ASSEMBLY REPLACEMENT IMPORTANT: Firmly push the quick connect onto the heater core hose until you hear an audible click.
2008 Chevrolet Silverado 1500 2008 HVAC Heating, Ventilation, and Air Conditioning - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 95: View Of Air Inlet Assembly & Components Callout Component Name Preliminary Procedure 1. Remove the HVAC module assembly. Refer to HVAC Module Assembly Replacement. 2. Disconnect the electrical connector from the recirculation actuator. 1 Recirculation Actuator Screw (Qty: 2) Tighten: 1.5 N.m (13 lb in) NOTE: Refer to Fastener Notice . 2 Recirculation Actuator 3 Air Inlet Assembly Screw (Qty: 2) Tighten: 1.5 N.m (13 lb in) Air Inlet Assembly
2008 Chevrolet Silverado 1500 2008 HVAC Heating, Ventilation, and Air Conditioning - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
BLOWER MOTOR CONTROL MODULE REPLACEMENT Fig. 96: View Of Blower Motor Control Module & Screws 4 Tip: Tilt the rear of the air inlet assembly upward to release front mounting Callout Component Name Preliminary Procedure 1. Remove the I/P insulator panel. Refer to Instrument Panel Insulator Replacement (with RPO SLT) or Instrument Panel Insulator Replacement (without RPO 2. Disconnect the blower motor control module electrical connector.
2008 Chevrolet Silverado 1500 2008 HVAC Heating, Ventilation, and Air Conditioning - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
