Fig. 47: View Of Discharge Hose At Condenser
Courtesy of GENERAL MOTORS CORP.

5. Remove the discharge hose nut from the condenser.

Discard the nut.

6. Remove the discharge hose from the condenser.

2008 Chevrolet Silverado 1500

2008 HVAC Heating, Ventilation, and Air Conditioning - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &

Silverado

7. Disconnect the A/C recirculation switch from the discharge hose.

8. Remove the discharge hose from the vehicle.

9. Discard all of the used sealing washers. Cap the system openings.

Installation Procedure

1. Install the discharge hose to the vehicle.

2. Connect the A/C recirculation switch to the discharge hose.

2008 Chevrolet Silverado 1500

2008 HVAC Heating, Ventilation, and Air Conditioning - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &

Silverado

Fig. 48: View Of Discharge Hose At Condenser
Courtesy of GENERAL MOTORS CORP.

3. Install the discharge hose to the condenser using new sealing washers.

4. Install the NEW discharge hose nut to the condenser.

NOTE:

Refer to Fastener Notice .

2008 Chevrolet Silverado 1500

2008 HVAC Heating, Ventilation, and Air Conditioning - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &

Silverado

Tighten: Tighten the nut to 16 N.m (12 lb ft).

5. Install the upper radiator air baffle. Refer to Radiator Air Upper Baffle and Deflector

Replacement .

Fig. 49: View Of Discharge Hose & Connectors
Courtesy of GENERAL MOTORS CORP.

6. Install the discharge hose (5) to the compressor using new sealing washers.

7. Install the NEW discharge hose mounting bolt (2) to the A/C compressor.

2008 Chevrolet Silverado 1500

2008 HVAC Heating, Ventilation, and Air Conditioning - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &

Silverado
