Tighten: Tighten the nuts to 113 N.m (83 lb ft).
4. Install the hitch platform bolts (5) to the bumper weld nuts (4).
Tighten: Tighten the bolts to 100 N.m (74 lb ft).
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Frame and Underbody - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra
& Silverado
2008 SUSPENSION
Front Suspension - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
REPAIR INSTRUCTIONS
Application
Specification
Metric
English
Brake Hose Bracket Bolt
9 N.m
80 lb in
Brake Hose Clip Bolts
12 N.m
106 lb in
Hub and Bearing Assembly to Steering Knuckle
Bolts
180 N.m
133 lb ft
Lower Ball Joint Stud Nut
110 N.m
81 lb ft
Lower Control Arm to Frame Nuts
175 N.m
129 lb ft
Shock Absorber Module to Frame Nuts
50 N.m
37 lb ft
Shock Absorber Module to Lower Control Arm
Bolt - 1500 Series
50 N.m
37 lb ft
Shock Absorber Module to Lower Control Arm Nut
- 2500 Series
80 N.m
59 lb ft
Shock Absorber Nut - 1500 Series
50 N.m
37 lb ft
Shock Absorber Nut - 2500 Series
24 N.m
17 lb ft
Shock Absorber to Lower Control Arm Bolts - 2500
Series
80 N.m
59 lb ft
Spring Jounce Bumper Nut - 2500 Series
30 N.m
22 lb ft
Stabilizer Shaft Insulator Clamp Bolts
50 N.m
37 lb ft
Stabilizer Shaft Link Nuts - 1500 Series
23 N.m
17 lb ft
Stabilizer Shaft Link Nuts - 2500 Series
23 N.m
17 lb ft
Torsion Bar Crossmember to Frame Bushing Bolt
95 N.m
70 lb ft
Torsion Bar Support Link Bolt
95 N.m
70 lb ft
Upper Ball Joint Stud Nut
50 N.m
37 lb ft
Upper Control Arm to Frame Nuts
190 N.m
140 lb ft
Wheel Drive Shaft to Front Hub Nut
240 N.m
177 lb ft
Wheel Speed Sensor Mounting Bolt
18 N.m
13 lb ft
2008 Chevrolet Silverado 1500
2008 SUSPENSION Front Suspension - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
2008 Chevrolet Silverado 1500
2008 SUSPENSION Front Suspension - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
STABILIZER SHAFT REPLACEMENT (2500, 3500)
Fig. 1: View Of Stabilizer Shaft (2500, 3500)
Courtesy of GENERAL MOTORS CORP.
STABILIZER SHAFT REPLACEMENT (1500)
Callout
Component Name
Preliminary Procedure
1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle .
2. Remove the front tire and wheel. Refer to Tire and Wheel Removal and
Installation .
3. Remove the engine shield, if equipped. Refer to Engine Shield Replacement .
4. Remove the stabilizer shaft insulators. Refer to Stabilizer Shaft Insulator
Replacement (1500) or Stabilizer Shaft Insulator Replacement (2500, 3500).
1
Front Stabilizer Shaft
2008 Chevrolet Silverado 1500
2008 SUSPENSION Front Suspension - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 2: View Of Stabilizer Shaft (1500)
Courtesy of GENERAL MOTORS CORP.
STABILIZER SHAFT LINK REPLACEMENT (2500/3500)
Callout
Component Name
Preliminary Procedures
1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle .
2. Remove the front stabilizer shaft links. Refer to Stabilizer Shaft Link Replacement
(2500/3500) or Stabilizer Shaft Link Replacement (1500).
3. Remove the front stabilizer shaft insulators. Refer to Stabilizer Shaft Insulator
Replacement (1500) or Stabilizer Shaft Insulator Replacement (2500, 3500).
1
Front Stabilizer Shaft
2008 Chevrolet Silverado 1500
2008 SUSPENSION Front Suspension - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
