Fig. 7: View Of Drivetrain and Front Suspension Frame Front Crossmember (4WD 2500 Callout Component Name Preliminary Procedure: 1 Engine Front Crossmember Nut (Qty: 4) Tighten: 120 N.m (89 lb ft) NOTE: Refer to Fastener Notice . 2 Engine Front Crossmember Bolt (Qty: 4) 1. Remove all traces of the original adhesive patch. 2. Clean the threads of the bolt with denatured alcohol or equivalent and
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Frame and Underbody - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
DRIVETRAIN AND FRONT SUSPENSION FRAME FRONT CROSSMEMBER REPLA Fig. 8: View Of Drivetrain and Front Suspension Frame Front Crossmember (2WD 2500 allow to dry. 3. Apply threadlocker GM P/N 12345493 (Canadian P/N 10953488). 3 Lower Control Arm Crossmember Callout Component Name Preliminary Procedure 1. Raise the vehicle. Refer to Lifting and Jacking the Vehicle . 2. Remove the oil pan skid plate. Refer to Oil Pan Skid Plate Replacement (2500/3500 with RPO NZZ). Engine Front Crossmember Nut (Qty: 2)
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Frame and Underbody - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
DRIVETRAIN AND FRONT SUSPENSION FRAME FRONT CROSSMEMBER REPLA 1 Tighten: 120 N.m (89 lb ft) NOTE: Refer to Fastener Notice . 2 Engine Front Crossmember Bolt (Qty: 2) 1. Remove all traces of the original adhesive patch. 2. Clean the threads of the bolt with denatured alcohol or equivalent and allow to dry. 3. Apply threadlocker GM P/N 12345493 (Canadian P/N 10953488). 3 Engine Front Crossmember Nut (Qty: 2) Tighten: 120 N.m (89 lb ft) 4 Engine Front Crossmember Bolt (Qty: 2) 1. Remove all traces of the original adhesive patch. 2. Clean the threads of the bolt with denatured alcohol or equivalent and allow to dry. 3. Apply threadlocker GM P/N 12345493 (Canadian P/N 10953488). 5 Lower Control Arm Crossmember
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Frame and Underbody - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 9: View Of Drivetrain and Front Suspension Frame Front Crossmember (1500, 2500 Callout Component Name Preliminary Procedure: 1 Engine Front Crossmember Nut (Qty: 4) Tighten: 50 N.m (37 lb ft) plus 120 degrees NOTE: Refer to Fastener Notice . Engine Front Crossmember Bolt (Qty: 4)
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Frame and Underbody - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
