Fig. 57: Ignition Coils & Bracket 8. Apply threadlock GM P/N 12345382 (Canadian P/N 10953489), or equivalent, to the threads of the ignition coil bracket studs (720). 9. Install the ignition coil and bracket assembly (719) and studs (720). Tighten: Tighten the bracket studs to 12 N.m (106 lb in). ENGINE BLOCK VALLEY COVER INSTALLATION
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 58: Removing/Installing Engine Valley Cover IMPORTANT: All gasket surfaces should be free of oil or other foreign material during assembly.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
1. Lubricate the O-ring seals with clean engine oil. 2. Install the O-ring seals (537) to the cover (555). 3. Install the cover (555), gasket (556), and bolts (506). Tighten: Tighten the manifold bolts to 25 N.m (18 lb ft). Fig. 59: Removing/Installing Oil Pressure Sensor & Washer 4. Apply sealant GM P/N 12346004 (Canadian P/N 10953480), or equivalent, to the threads of the sensor. 5. Install the oil pressure sensor (706) and sealing washer (707). Tighten: Tighten the sensor to 35 N.m (26 lb ft). NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
VALVE LIFTER OIL FILTER INSTALLATION Fig. 60: View Of Oil Pressure Sensor, Washer And Valve Lifter Oil Filter 1. Install a NEW oil filter (452) and O-ring (454) assembly. 2. Apply sealant GM P/N 12346004 (Canadian P/N 10953480) to the threads of the sensor. IMPORTANT: Do not allow dirt or debris to enter the oil passages of the manifold. Plug, as required. NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
