J 41816-2 Crankshaft End Protector. See Special Tools .
J 42386-A Flywheel Holding Tool. See Special Tools .
Removal
Fig. 271: View Of Flex Plate & Bolts
Courtesy of GENERAL MOTORS CORP.
IMPORTANT:
Do not use the camshaft position (CMP) actuator
solenoid valve again. Upon installation of the CMP
actuator and timing chain, install a NEW valve.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
1. Temporarily install the automatic transmission flex plate and bolts. Refer to Automatic
Transmission Flex Plate Installation .
Fig. 272: View Of Special Tool & Bolts
Courtesy of GENERAL MOTORS CORP.
Do not apply threadlock to the flex plate bolts at this
time.
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
2. Install the J 42386-A (1) and bolts. See Special Tools . Use 1 M10 - 1.5 x 120 mm and 1
M10 - 1.5 x 45 mm bolt for proper tool operation.
Tighten: Tighten the J 42386-A bolts to 50 N. See Special Tools .m (37 lb ft).
Fig. 273: View Of CMP Actuator Solenoid Valve
Courtesy of GENERAL MOTORS CORP.
3. Remove the CMP actuator solenoid valve (234).
4. Discard the solenoid valve.
