Chevrolet Silverado / GMC Sierra. Manual - part 2092
Fig. 235: View Of Cylinder Head & Bolts
Courtesy of GENERAL MOTORS CORP.
1. Remove the cylinder head bolts (220, 221).
2. Remove the cylinder head (218).
IMPORTANT: The cylinder head bolts are of a torque-to-yield design and
are NOT to be used again. Install NEW cylinder head bolts
during assembly.
NOTE:
After removal, place the cylinder head on 2 wood blocks in
order to prevent damage to the sealing surfaces.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 236: View Of Cylinder Head Gasket & Locating Pins
Courtesy of GENERAL MOTORS CORP.
3. Remove the gasket (217) and locating pins (230).
4. Discard the gasket and cylinder head bolts.
CYLINDER HEAD REMOVAL - RIGHT SIDE
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 237: View Of Cylinder Head & Bolts
Courtesy of GENERAL MOTORS CORP.
1. Remove the cylinder head bolts (220, 221).
2. Remove the cylinder head (218).
IMPORTANT: The cylinder head bolts are of a torque-to-yield design and
are NOT to be used again. Install NEW cylinder head bolts
during assembly.
NOTE:
After removal, place the cylinder head on 2 wood blocks in
order to prevent damage to the sealing surfaces.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 238: View Of Cylinder Head Gasket & Locating Pins
Courtesy of GENERAL MOTORS CORP.
3. Remove the gasket (217) and locating pins (230).
4. Discard the gasket and cylinder head bolts.
VALVE LIFTER REMOVAL (RPO LY2/LY6/L92)
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
