Fig. 219: View Of Oil Pressure Sensor, Washer And Valve Lifter Oil Filter 1. Remove the oil pressure sensor (706). 2. Remove the oil filter (452). 3. Inspect the O-ring (454) for cuts or damage. If the filter is plugged or the O-ring is cut or damaged, replace the filter and O-ring as an assembly. VALVE ROCKER ARM COVER REMOVAL - LEFT SIDE IMPORTANT: Do not allow dirt or debris to enter the oil passages of the manifold. Plug, as required.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 220: Ignition Coils & Bracket 1. Remove the spark plug wires (724). 2. Remove the ignition coil bracket studs (720). 3. Remove the ignition coil and bracket assembly (719).
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 221: View Of Bracket, Bolts, Coils & Wire Harness 4. Disconnect the ignition coil electrical connectors. 5. Remove the bolts (723), coils (722), and wire harness (721) from the bracket (719), as required.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 222: View Of Valve Rocker Arm Cover 6. Remove the valve rocker arm cover bolts and cover.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
