4. Remove the O-ring (421) from the tube, as required. EXHAUST MANIFOLD REMOVAL - LEFT SIDE Fig. 187: Exhaust Manifold 1. Remove the spark plug wires from the spark plugs. 2. Remove the exhaust manifold, bolts, and gasket. 3. Discard the gasket. be used again if it is not cut or damaged.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 188: Exhaust Manifold 4. Remove the heat shield (603) and bolts (604) from the manifold (600), as required. 5. Remove the studs (605), as required. EXHAUST MANIFOLD REMOVAL - RIGHT SIDE
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 189: Exhaust Manifold 1. Remove the spark plug wires from the spark plugs. 2. Remove the exhaust manifold, bolts, and gasket. 3. Discard the gasket.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 190: Exhaust Manifold 4. Remove the heat shield (603) and bolts (604) from the manifold (600), as required. 5. Remove the studs (605), as required. WATER PUMP REMOVAL (RPO LY2/LH6/LMG/LY5/LC9)
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
