Courtesy of GENERAL MOTORS CORP. 3. Use the J 41816-A (1) and the J 41816-2 (2) in order to remove the crankshaft balancer. See Special Tools . Fig. 183: View Of Crankshaft Balancer 4. Remove the balancer (138).
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 184: View Of Special Tool & Bolts 5. Remove the J 42386-A (1) and bolts. See Special Tools . AUTOMATIC TRANSMISSION FLEX PLATE REMOVAL
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 185: View Of Flex Plate & Bolts 1. Remove the engine flex plate bolts. 2. Remove the flex plate. IMPORTANT: The flex plate does not use a locating pin for alignment and will not initially seat against the crankshaft flange, but will
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
OIL LEVEL INDICATOR AND TUBE REMOVAL Fig. 186: View Of Oil Level Indicator, Tube Bolt, Indicator Tube & O-Ring Seal 1. Remove the oil level indicator (418) from the tube. 2. Remove the oil level indicator tube bolt (419). 3. Remove the oil level indicator tube (420) from the engine block. IMPORTANT: Inspect the O-ring for cuts or damage. The O-ring seal may
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
