Fig. 123: View Of Oil Level Indicator Tube & Seal
Courtesy of GENERAL MOTORS CORP.
52. Remove the transmission oil level indicator tube.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 124: View Of J 41798
Courtesy of GENERAL MOTORS CORP.
53. Install the J 41798 to the cylinder heads. See Special Tools .
Tighten:
Tighten the M8 engine lift bracket bolts to 25 N.m (18 lb ft).
Tighten the M10 engine lift bracket bolts to 50 N.m (37 lb ft).
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 125: View Of Engine Mount To Frame Bolts
Courtesy of GENERAL MOTORS CORP.
54. For 1500 series vehicles with a 4.8L engine, remove the left and right engine mount to
frame bolts (1).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 126: View Of Engine Mount To Frame Bolts
Courtesy of GENERAL MOTORS CORP.
55. For 1500 series vehicles with a 5.3L, 6.0L, or 6.2L engines, remove the left and right engine
mount to frame bolts (1).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
