Chevrolet Silverado / GMC Sierra. Manual - part 1944
Fig. 153: View Of MAP Sensor & Retainer
Courtesy of GENERAL MOTORS CORP.
37. Remove the manifold absolute pressure (MAP) sensor retainer.
38. Remove the MAP sensor.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 154: View Of EVAP Tube & Purge Solenoid
Courtesy of GENERAL MOTORS CORP.
39. Disconnect the EVAP tube quick connect fitting at the intake manifold. Refer to Plastic
Collar Quick Connect Fitting Service .
40. Disengage the retainer securing the EVAP canister purge solenoid to the fuel rail.
41. Remove the EVAP tube and purge solenoid.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 155: View Of Throttle Body, Gasket & Bolts/Nuts
Courtesy of GENERAL MOTORS CORP.
42. Remove the throttle body bolts/nuts.
43. Remove the throttle body.
44. Remove and discard the throttle body gasket.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 156: View Of Fuel Rail & Bolts
Courtesy of GENERAL MOTORS CORP.
45. Remove the fuel rail bolts.
IMPORTANT: Lift evenly on both sides of the fuel rail until all injectors are
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
