Fig. 95: View Of EVAP Tube & Purge Solenoid 10. Install the EVAP tube and purge solenoid. 11. Install the EVAP canister purge solenoid to the fuel rail bracket and engage the retainer. 12. Connect the EVAP tube quick connect fitting at the intake manifold. Refer to Plastic Collar Quick Connect Fitting Service .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 96: View Of MAP Sensor & Retainer 13. Lubricate the MAP sensor seal with clean engine oil. 14. Install the MAP sensor. 15. Install the MAP sensor retainer.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 97: View Of Upper Intake Manifold Cover & Nut 16. Install the upper intake manifold cover. 17. Install the upper intake manifold cover nut until snug
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 98: View Of Vacuum Brake Booster Hose 18. Install the brake booster vacuum hose to the intake manifold nipple. 19. Position the brake booster vacuum hose clamp at the intake manifold. 20. Secure the brake booster vacuum hose to the intake manifold.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
