Fig. 107: View Of Oil Pan Skid Plate & Bolts 23. Install the transmission crossmember. Refer to Transmission Support Crossmember Replacement (2WD 2500 HD/3500) or Transmission Support Crossmember 24. Position the oil pan skid plate and install the oil pan skid plate bolts, if equipped. Tighten: Tighten the bolts to 28 N.m (21 lb ft). 25. Lower the vehicle.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Exhaust - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
CATALYTIC CONVERTER REPLACEMENT (4.8L, 5.3L, 6.0L, 6.2L) Removal Procedure Fig. 108: View Of Oil Pan Skid Plate & Bolts 1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . 2. Remove the oil pan skid plate bolts and skid plate, if equipped. 3. Remove the transmission crossmember. Refer to Transmission Support Crossmember Replacement (2WD 2500 HD/3500) or Transmission Support Crossmember
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Exhaust - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 109: View Of Engine Wiring Harness Electrical Connectors, (CPA) Retainers & 4. Remove the right front connector position assurance (CPA) retainer (2). 5. Disconnect the right front heated oxygen sensor (HO2S) electrical connector from the engine wiring harness electrical connector (1).
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Exhaust - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
6. Remove the right rear CPA retainer (4). 7. Disconnect the engine wiring harness electrical connector (3) from the right rear HO2S electrical connector. 8. Remove the right rear HO2S electrical connector clip from the engine harness clip (5). Fig. 110: View Of Left Rear CPA Retainer & Engine Wiring Harness Electrical 9. Remove the left rear CPA retainer (1). 10. Disconnect the left rear HO2S electrical connector from the engine wiring harness electrical connector (3).
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Exhaust - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
