Chevrolet Silverado / GMC Sierra. Manual - part 1775
Fig. 274: View Of Generator, Bracket & Bolts
Courtesy of GENERAL MOTORS CORP.
1. Install the generator bracket onto the stud.
2. Install the generator bracket bolts and nut.
Tighten: Tighten the bolts/nut to 41 N.m (30 lb ft).
3. Install the drive belt idler pulley. Refer to Drive Belt Idler Pulley Replacement - Right
Side .
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
4. Install the drive belt tensioner. Refer to Drive Belt Tensioner Replacement .
5. Install the generator. Refer to Generator Replacement (4.3L) or Generator
Replacement (4.8L, 5.3L, 6.0L, and 6.2L) or Generator Replacement (6.6L).
GENERATOR BRACKET REPLACEMENT (4.8L, 5.3L, 6.0L, AND 6.2L)
Removal Procedure
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 275: View Of Engine Wiring Harness, Clip, Bolt & Connector
Courtesy of GENERAL MOTORS CORP.
1. Remove the generator. Refer to Generator Replacement (4.3L) or Generator
Replacement (4.8L, 5.3L, 6.0L, and 6.2L) or Generator Replacement (6.6L).
2. Remove the power steering pump. Refer to Power Steering Pump Replacement (4.3L) or
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Power Steering Pump Replacement (4.8L, 5.3L, 6.0L, and 6.2L) or Power Steering
Pump Replacement (6.6L) .
3. Remove the engine wiring harness clip bolt (3) are reposition the clip (1) away from the
generator bracket.
Fig. 276: View Of Generator Bracket & Bolts (4.8L, 5.3L & 6.0L)
Courtesy of GENERAL MOTORS CORP.
4. Remove the generator bracket bolts.
5. Remove the generator bracket.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
