Chevrolet Silverado / GMC Sierra. Manual - part 1765
Fig. 234: View Of Oil Pan Skid Plate & Bolts
Courtesy of GENERAL MOTORS CORP.
9. Position the oil pan skid plate and install the bolts, if equipped.
Tighten: Tighten the bolts to 28 N.m (21 lb ft).
10. Lower the vehicle.
11. Connect the negative battery cable. Refer to Battery Negative Cable Disconnection and
Connection (w/Single Battery) or Battery Negative Cable Disconnection and
Connection (w/Auxiliary Battery) or Battery Negative Cable Disconnection and
Connection (w/Dual Batteries).
STARTER MOTOR REPLACEMENT (4.8L, 5.3L, 6.0L, AND 6.2L)
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Removal Procedure
Fig. 235: View Of Oil Pan Skid Plate & Bolts
Courtesy of GENERAL MOTORS CORP.
1. Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection
and Connection (w/Single Battery) or Battery Negative Cable Disconnection and
Connection (w/Auxiliary Battery) or Battery Negative Cable Disconnection and
Connection (w/Dual Batteries).
2. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle .
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 236: View Of Oil Pan Skid Plate & Bolts
Courtesy of GENERAL MOTORS CORP.
3. For 2500 series vehicles, remove the front 2 oil pan skid plate bolts, loosen the rear 2 bolts
and remove the skid plate, if equipped.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
