Chevrolet Silverado / GMC Sierra. Manual - part 1743
Fig. 149: View Of Oil Pan Skid Plate & Bolts
Courtesy of GENERAL MOTORS CORP.
14. For 2500 series vehicles, install the oil pan skid plate and tighten the rear 2 bolts and install
and tighten the front 2 bolts.
Tighten: Tighten the bolts to 28 N.m (21 lb ft).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 150: View Of Oil Pan Skid Plate & Bolts
Courtesy of GENERAL MOTORS CORP.
15. For 1500 series vehicles, install the oil pan skid plate and bolts.
Tighten: Tighten the bolts to 28 N.m (21 lb ft).
16. Lower the vehicle.
17. Install the air cleaner outlet duct. Refer to Air Cleaner Resonator Outlet Duct
Replacement .
18. Connect the negative battery cable. Refer to Battery Negative Cable Disconnection and
Connection (w/Single Battery) or Battery Negative Cable Disconnection and
Connection (w/Auxiliary Battery) or Battery Negative Cable Disconnection and
Connection (w/Dual Batteries).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
STARTER SOLENOID CABLE REPLACEMENT (6.6L)
Removal Procedure
Fig. 151: View Of Negative Battery Cable & Components
Courtesy of GENERAL MOTORS CORP.
1. Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
and Connection (w/Single Battery) or Battery Negative Cable Disconnection and
Connection (w/Auxiliary Battery) or Battery Negative Cable Disconnection and
Connection (w/Dual Batteries).
2. Remove the air cleaner assembly. Refer to Air Cleaner Assembly Replacement .
3. Open the starter solenoid cable positive battery post cover.
4. Loosen the starter solenoid cable nut (1).
5. Remove the starter solenoid cable from the battery positive post.
Fig. 152: View Of Battery Components
Courtesy of GENERAL MOTORS CORP.
6. Open the starter solenoid cable positive battery post cover (1).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
