Fig. 145: View Of Battery Cable Components 2. Install the starter solenoid cable to the positive battery terminal. 3. Tighten the starter solenoid cable nut (5). Tighten: Tighten the nut to 5 N.m (44 lb in). NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
4. Close the starter solenoid cable cover at the positive battery terminal. 5. Install the starter solenoid cable terminal (2) to the mega fuse stud. 6. Install the starter solenoid cable nut (1) to the mega fuse stud. Tighten: Tighten the nut to 9 N.m (80 lb in). 7. Install the starter solenoid cable clip (4) to the A/C evaporator tube. Fig. 146: View Of Mega Fuse Cover 8. Install the mega fuse cover. 9. Raise the vehicle.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 147: View Of Starter Solenoid Cable & Nut 10. Install the starter solenoid cable (2) to the starter. 11. Install the starter solenoid cable nut (1) to the starter. Tighten: Tighten the nut to 9 N.m (80 lb in).
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 148: View Of Starter Solenoid Cable Clip & Bolt 12. Position the starter solenoid cable clip to the frame and install the starter solenoid cable clip bolt (2). 13. Install the starter solenoid cable clip (1) to the wheelhouse panel.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
