Fig. 74: View Of Positive Battery Cable Channel, Clips & Studs
Courtesy of GENERAL MOTORS CORP.
9. Remove the positive battery cable channel from the studs on the plenum front panel.
10. Remove the positive battery cable clips from the studs on the plenum front panel.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 75: View Of Positive Battery Cable
Courtesy of GENERAL MOTORS CORP.
11. Remove the positive battery cable terminal from the mega fuse stud.
12. Remove the positive battery cable channel from the studs.
13. Remove the positive battery cable from the vehicle.
Installation Procedure
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 76: View Of Positive Battery Cable
Courtesy of GENERAL MOTORS CORP.
1. Install the positive battery cable to the vehicle.
2. Install the positive battery cable terminal to the mega fuse stud.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 77: View Of Positive Battery Cable Channel, Clips & Studs
Courtesy of GENERAL MOTORS CORP.
3. Install the positive battery cable channel at the plenum front panel.
4. Install the positive battery cable clips to the studs on the plenum front panel.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
