Fig. 24: View Of Battery Cable Clips
Courtesy of GENERAL MOTORS CORP.
12. Remove the negative battery cable clip (1) from the chassis harness.
13. Lower the vehicle.
14. Remove the negative battery cable clip (2) from the right wheelhouse liner.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 25: View Of Negative Battery Cable
Courtesy of GENERAL MOTORS CORP.
15. Remove the negative battery cable from the vehicle.
16. If replacing the negative battery cable, remove the battery current sensor. Refer to Battery
Current Sensor Replacement (4.3L) or Battery Current Sensor Replacement (4.8L,
5.3L, 6.0L, and 6.2L).
Installation Procedure
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 26: View Of Negative Battery Cable
Courtesy of GENERAL MOTORS CORP.
1. If the negative battery cable was replaced, install the battery current sensor. Refer to
Battery Current Sensor Replacement (4.3L) or Battery Current Sensor Replacement
(4.8L, 5.3L, 6.0L, and 6.2L).
2. Install the negative battery cable to the vehicle.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 27: View Of Battery Cable Clips
Courtesy of GENERAL MOTORS CORP.
3. Install the negative battery cable clip (2) to the right wheelhouse liner.
4. Raise and support the vehicle.
5. Install the negative battery cable clip (1) to the chassis harness.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
