Chevrolet Silverado / GMC Sierra. Manual - part 1709
4. Mark the location of the negative battery cable clips (1) and remove the clips from the
cable.
5. Squeeze the negative battery cable branches together.
6. Slide the battery current sensor (2) off of the negative battery cable.
Installation Procedure
IMPORTANT: Note the orientation of the battery current sensor prior to
removal.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 18: View Of Battery Cable & Current Sensor
Courtesy of GENERAL MOTORS CORP.
1. Squeeze the negative battery cable branches together.
2. Slide the NEW battery current sensor (2) up onto the negative battery cable to the location
IMPORTANT: Ensure the battery current sensor is installed in the correct
direction and location on the negative battery cable.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
previously marked during removal.
3. Wrap electrical tape around the battery current sensor leg in order to secure the sensor to
the negative battery cable.
4. Install the negative battery cable clips (1) to the cable to the locations previously marked
during removal.
5. Install the negative battery cable. Refer to Battery Negative Cable Replacement (4.3L)
or Battery Negative Cable Replacement (4.8L, 5.3L, 6.0L, and 6.2L) or Battery
Negative Cable Replacement (6.6L).
BATTERY NEGATIVE CABLE REPLACEMENT (4.3L)
Removal Procedure
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 19: View Of Engine Harness Electrical Connector & Battery Current Sensor
Courtesy of GENERAL MOTORS CORP.
1. Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection
and Connection (w/Single Battery) or Battery Negative Cable Disconnection and
Connection (w/Auxiliary Battery) or Battery Negative Cable Disconnection and
Connection (w/Dual Batteries).
2. Remove the air cleaner outlet resonator. Refer to Air Cleaner Outlet Resonator
Replacement .
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
