Chevrolet Silverado / GMC Sierra. Manual - part 1649
Fig. 139: View Of Manifold Intake Temperature Sensor Electrical Connector &
Water Tube
Courtesy of GENERAL MOTORS CORP.
5. Install the manifold intake temperature sensor electrical connector to the water tube bracket.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Cooling - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 140: View Of Main Electrical Connector Harness Bracket & Bolts
Courtesy of GENERAL MOTORS CORP.
6. Install the main electrical harness bracket.
7. Install the main electrical harness bracket bolts.
Tighten: Tighten the bolts to 21 N.m (15 lb ft).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Cooling - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 141: View Of Main Engine Electrical Harness Connector Bolts
Courtesy of GENERAL MOTORS CORP.
8. Install the main engine electrical harness connector bolts.
Tighten: Tighten the bolts to 10 N.m (89 lb in).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Cooling - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 142: View Of Main Electrical Connector Harness Bracket & Bolts
Courtesy of GENERAL MOTORS CORP.
9. Install the main electrical connector harness bracket (2).
10. Install the main electrical connector harness bracket bolts (1).
Tighten: Tighten the bolts to 21 N.m (15 lb ft).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Cooling - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
