REAR BRAKE CALIPER REPLACEMENT (JH6, JH7) Fig. 19: Brake Caliper Bracket Bolts 3. Slowly release the brake pedal. 4. Wait 15 seconds, then repeat steps 2-3 until a firm brake pedal is obtained. This will properly seat the brake caliper piston and the brake pads. 5. Fill the master cylinder to the proper level. Refer to Master Cylinder Reservoir Filling . Callout Component Name Preliminary Procedures CAUTION: Refer to Brake Dust Caution . CAUTION: Refer to Brake Fluid Irritant Caution .
2008 Chevrolet Silverado 1500 2008 BRAKES Disc Brakes - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . 2. Remove the tire and wheel assembly. Refer to Tire and Wheel Removal and Installation . 1 Brake Hose Fitting Bolt Tighten: 40 N.m (30 lb ft) NOTE: Refer to Fastener Notice . 2 Brake Hose Fitting Gasket (Qty: 2) 3 Rear Brake Hose Fitting 4 Brake Caliper Guide Pin Bolt (Qty: 2) Tighten: 108 N.m (80 lb ft) 5 Brake Caliper Bracket Bolt (Qty: 2) Procedure 1. Remove all traces of the adhesive patch on the brake caliper bracket bolts and threaded holes of the brake caliper bracket. 2. Clean the brake caliper bracket bolt threads and the threaded holes of the brake caliper bracket with denatured alcohol or equivalent and allow to 3. Apply threadlocker G/M P/N 12345493 (Canadian P/N 10953488) to 2/3 of the threaded portion of the brake caliper bracket bolts. Tighten: JH6: 200 N.m (148 lb in) JH7: 300 N.m (221 lb ft) 6 Brake Caliper Bracket
2008 Chevrolet Silverado 1500 2008 BRAKES Disc Brakes - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
REAR BRAKE CALIPER REPLACEMENT (JD9) Fig. 20: View Of Rear Brake Caliper Components Remove the upper brake caliper guide pin bolt. 7 Brake Caliper Procedure 1. Bleed the hydraulic brake system. Refer to Hydraulic Brake System Bleeding (Pressure) or Hydraulic Brake System Bleeding (Manual) . 2. After the installation is complete and with the engine OFF, gradually apply the brake pedal to approximately 2/3 of its travel distance. 3. Slowly release the brake pedal. 4. Wait 15 seconds, then repeat steps 2-3 until a firm brake pedal is obtained. This will properly seat the brake caliper pistons and the brake pads. 5. Fill the master cylinder to the proper level. Refer to Master Cylinder Reservoir Filling . Callout Component Name CAUTION:
2008 Chevrolet Silverado 1500 2008 BRAKES Disc Brakes - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Preliminary Procedures 1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . 2. Remove the tire and wheel assembly. Refer to Tire and Wheel Removal and Installation . Refer to Brake Dust Caution . CAUTION: Refer to Brake Fluid Irritant Caution . 1 Brake Hose Fitting Bolt Tighten: 40 N.m (30 lb ft) NOTE: Refer to Fastener Notice . 2 Brake Hose Fitting Gasket (Qty: 2) 3 Brake Hose Fitting 4 Brake Caliper Guide Pin Bolt (Qty: 2) Procedure 1. DO NOT use any air tools to remove or install the brake caliper guide pin bolts. Use hand tools ONLY. 2. Install an open end wrench to hold the caliper guide pin in line with the brake caliper while removing or installing the caliper guide pin bolts. DO 3. Ensure the brake caliper guide pin seal is fully seated in the groove of the brake caliper guide pin and the guide pin slides freely in caliper bracket Tighten: 38 N.m (28 lb ft) Brake Caliper
2008 Chevrolet Silverado 1500 2008 BRAKES Disc Brakes - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
