Chevrolet Silverado / GMC Sierra. Manual - part 1446
Fig. 166: Removing Pinion
Courtesy of GENERAL MOTORS CORP.
6. Remove the pinion.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 167: View Of Collapsible Spacer
Courtesy of GENERAL MOTORS CORP.
7. Remove the collapsible spacer.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 168: Removing Inner Pinion Bearing Using Hydraulic Press
Courtesy of GENERAL MOTORS CORP.
8. Using the J 22912-B and a hydraulic press, remove the inner pinion bearing from the
pinion.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 169: Removing Outer Pinion Bearing Cup
Courtesy of GENERAL MOTORS CORP.
IMPORTANT: Insert the brass drift in the slots to remove the bearing cup.
IMPORTANT: Move the drift back and forth between one side of the cup
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
