Chevrolet Silverado / GMC Sierra. Manual - part 1354
Fig. 123: View Of Differential Carrier Upper Mounting Bolt
Courtesy of GENERAL MOTORS CORP.
4. Install the differential carrier assembly upper mounting bolt and the nut.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 124: View Of Inner Axle Housing Nuts
Courtesy of GENERAL MOTORS CORP.
5. Install the inner axle housing washers and nuts to the bracket.
Tighten:
Tighten the inner axle housing nuts to 100 N.m (75 lb ft).
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Tighten the upper and the lower differential carrier assembly bolts to 100 N.m (75 lb
ft).
Fig. 125: View Of Vent Hose To Differential Carrier Assembly
Courtesy of GENERAL MOTORS CORP.
6. Connect the vent hose to the differential carrier assembly.
7. Remove the transmission jack.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 126: View Of Wire Harness To Differential Carrier Assembly (S4WD)
Courtesy of GENERAL MOTORS CORP.
8. Connect the wire harness to the differential carrier assembly, S4WD axle only.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
