Chevrolet Silverado / GMC Sierra. Manual - part 1330
Fig. 35: Locating Vent Hose & Components
Courtesy of GENERAL MOTORS CORP.
3. Install the vent hose retainers to the frame.
4. Install the vent hose to the connector.
5. Install the engine shield, if equipped. Refer to Engine Shield Replacement .
6. Lower the vehicle.
VENT HOSE REPLACEMENT (9.25 INCH AXLE)
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Removal Procedure
Fig. 36: Vent Hose & Wiring Bundle
Courtesy of GENERAL MOTORS CORP.
1. Raise the vehicle. Refer to Lifting and Jacking the Vehicle .
2. Remove the engine shield, if equipped. Refer to Engine Shield Replacement .
3. Remove the vent hose (1) from the wiring bundle (2), S4WD axles only.
4. Remove the vent hose from the retainer clips, all axles.
IMPORTANT: Make note of the routing in order to aid in reassembly.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 37: View Of Vent Hose To Differential Carrier Assembly
Courtesy of GENERAL MOTORS CORP.
5. Remove the vent hose from the differential carrier assembly.
6. Remove the vent hose from the vehicle.
Installation Procedure
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 38: View Of Vent Hose To Differential Carrier Assembly
Courtesy of GENERAL MOTORS CORP.
1. Install the vent hose to the vehicle.
Route the vent hose the same way as when removed.
Ensure the hose is free of kinks and routes clear of sharp components.
Ensure the vent hose is not plugged.
2. Connect the vent hose to the differential carrier assembly.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
