2. Install the front differential carrier shield bolts.
Tighten: Tighten the front differential carrier shield bolts to 20 N.m (15 lb ft).
3. Lower the vehicle.
VENT HOSE REPLACEMENT (8.25 INCH AXLE)
Removal Procedure
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 32: Locating Vent Hose & Components
Courtesy of GENERAL MOTORS CORP.
1. Raise the vehicle. Refer to Lifting and Jacking the Vehicle .
2. Remove the engine shield, if equipped. Refer to Engine Shield Replacement .
3. Remove the vent hose the retainers from the frame.
4. Remove the vent hose from the connector.
5. Lower the vehicle.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 33: View Of Vent Hose
Courtesy of GENERAL MOTORS CORP.
6. Remove the vent hose from the inner fender.
Installation Procedure
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
