Fig. 13: View Of Welded Frame
Courtesy of GENERAL MOTORS CORP.

7. Clean and prepare all of the welded surfaces.

8. Install all of the related panels and components.

9. Connect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection

(w/Single Battery) or Battery Negative Cable Disconnection and Connection (w/Auxiliary Battery)
or Battery Negative Cable Disconnection and Connection (w/Dual Batteries) .

10. Enable the SIR system. Refer to SIR Disabling and Enabling .

OUTER WINDSHIELD FRAME PILLAR SECTIONING

Removal Procedure

CAUTION: Refer to Approved Equipment for Collision Repair Caution .

CAUTION: Refer to Glass and Sheet Metal Handling Caution .



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Collision Repair - - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &

Silverado



Microsoft



Friday, August 21, 2009 2:20:59 PM

Page 14

© 2005 Mitchell Repair Information Company, LLC.

CAUTION: Refer to Collision Sectioning Caution .



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Collision Repair - - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &

Silverado



Microsoft



Friday, August 21, 2009 2:20:59 PM

Page 15

© 2005 Mitchell Repair Information Company, LLC.

Fig. 14: View Of Sectioned Frame Areas
Courtesy of GENERAL MOTORS CORP.

IMPORTANT: The door frame can be replaced at the factory seams, but requires the



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Collision Repair - - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &

Silverado



Microsoft



Friday, August 21, 2009 2:20:59 PM

Page 16

© 2005 Mitchell Repair Information Company, LLC.

1. Disable the SIR system. Refer to SIR Disabling and Enabling .

2. Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection

(w/Single Battery) or Battery Negative Cable Disconnection and Connection (w/Auxiliary Battery)
or Battery Negative Cable Disconnection and Connection (w/Dual Batteries) .

3. Remove all related panels and components.

4. Repair as much of the damage as possible to factory specifications. Refer to Dimensions - Body.

5. Note the location and remove the sealers and anti-corrosion materials from the repair area, as necessary.

Refer to Anti-Corrosion Treatment and Repair .

6. Perform additional sectioning procedures as necessary. Refer to the following procedures:



Rocker Outer Panel Sectioning



Front Hinge Pillar Sectioning



Center Pillar Sectioning



Rear Pillar Sectioning

removal of the windshield, roof, and quarter panel. The sectioning
procedures have been developed as a more cost-effective alternative to
complete replacement. The specific area to be sectioned is determined by
the extent of the damage to the vehicle.

CAUTION: Refer to Foam Sound Deadeners Caution .
