Fig. 12: View Of Wheel Drive Shaft
Courtesy of GENERAL MOTORS CORP.

11. Remove the wheel drive shaft through the lower control arm opening.

12. Remove all dirt and debris from the splines on the wheel hub/bearing.

Installation Procedure

2008 Chevrolet Silverado 1500

2008 DRIVELINE/AXLE Wheel Drive Shafts - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado

Fig. 13: View Of Wheel Drive Shaft
Courtesy of GENERAL MOTORS CORP.

1. Install the wheel drive shaft in the steering knuckle.

2008 Chevrolet Silverado 1500

2008 DRIVELINE/AXLE Wheel Drive Shafts - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado

Fig. 14: View Of Hub Nut & Washer
Courtesy of GENERAL MOTORS CORP.

2. Install the NEW nut (1) and washer (2).

IMPORTANT: Install the NEW nut and washer, but DO NOT tighten at this

time.

2008 Chevrolet Silverado 1500

2008 DRIVELINE/AXLE Wheel Drive Shafts - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado

Fig. 15: View Of Drive Flange & Retaining Bolts
Courtesy of GENERAL MOTORS CORP.

3. Install the retaining bolts and finger tighten.

2008 Chevrolet Silverado 1500

2008 DRIVELINE/AXLE Wheel Drive Shafts - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
